SOMAX Technology is proud to work together with its technology partners to create an expansive network of best-in-class products that link together seamlessly.Rather than purchasing a single proprietary solution, you can integrate to create a security platform that exceeds your security needs.
MicroStream Image Quality Technology
Different objects will reflect different colors in a different light situation, every pixel on the "Micro-Stream" series cameras is equivalent to a photographic lens, which can absorb a different RGB color on each layer, the Micro-Stream cameras will show you a more real bright scene.
UP TO 5MP High Resolution
High Snr, Image Clear and Exquisite
IR-Cut Filter with Smart IR Control
Low Power Consumption
Auto Color to B/W
CVBS 30Fps @ 27MHz
The express setup page allows the user to set the most important parameters of DVR, such as time, network, recording parameters, etc. Even if the customers is not familiar with the DVR, he can operate the DVR easily and quickly.
Built-in help document, and can guide users to set up common functions quickly: such as how to access through the network, how to use the phone function, how to realize an alarm email function.
Support snapshot and setting of the snapshot schedule, Support to retrieve the pictures directly on the device side, user-friendly management of all information
Supported 28 languages, available to add more additional language
Alarm trigger conditions - includes motion detect, screen covered, video loss, sensor alarm, no-hard disk, hard disk error, hard disk full, network disconnected, the IP Address conflict, Complete Alarm linkage function, can be linked to Buzzer, OSD display, the screen notice, Recording, Tour, Snapshot, PTZ preset position, Alarm e-mail, FTP upload, Alarm output.
WIFI function only supports WEP encryption, does not support WPA encryption, you need to set the wireless router encryption settings for WEP encryption.
The password must be 10 to 26 hexadecimal characters;
The search function will find the wireless router in range, the SSID is the name of the mark of the router, then set up a wireless IP address in this network segment.
Supported to realize 3G function via USB port. Supported 3G standard: includes WCDMA, CDMA2000, TD-CDMA, etc.
Support SD Card Slot with Kingston SD Card with 32G Maximum
Connect the video signal input from the DVR and video signal out to the needs of the video signal monitor.
Selected models come complete with HDMI output able to upscale image to 1080p(1920*1080) alongside VGA and BNC outputs to make advantage of the latest monitor formats.
Support NTP (network timing), SADP (automatically search for the IP address), SMTP (mail service), the FTP (file upload), RTSP (Real Time Streaming Protocol), the UPNP (automatic mapping of ports), PPPoE(dial-up)agreement.
Strengthen the DVR network safety, and prevent the illegal users changing the DVR settings through network
Support disk partition management and redundancy functions
In addition to the normal setting of the authority division, the authority of preview and playback can be set in each channel.
Support multi-file batch backup, and support backup the video files in specified time period.
Support backup video files in AVI format via DVR, IE and CMS
You can play video files saved on an external backup device in the DVR locally
Android,IOS,RIM support download and install the vMeye software from the corresponding app store. Iphone support up to 4 channel viesing simultaneously.
Notice for multi-browser except IE:
Safari support multi-channel preview at the same time, Firefox, Chrome is only supports 1 channel preview currently.
The function only for remote surveillance and PTZ control currently.
The computer needs to install QUICKTIME player.
Make sure the RTSP service in network service is enabled.
When choosing to search the video data by time, it supports simultaneous playback of all channels
When an alarm event was prompted at the device end, if the linkage display is set in IE/CMS, it will prompt with a window of the alarm log for current alarm event.
Quick Operation and Setup
IP VS Analog Surveillance
The most obvious benefit of video surveillance is improved security. Whether you’re using security cameras to protect your home, business, or a large-scale campus environment, high-quality surveillance footage is an invaluable asset.
Pros of Analog Surveillance
Lower initial cost – Generally, analog cameras cost less than IP network cameras.
Greater compatibility – With an analog system it’s easy to mix and match camera models and surveillance equipment from different manufacturers.
Low-Light Performance – On average, analog cameras handle low light better than IP cameras.
Cons of Analog Surveillance
Limited feature set – Many advanced IP camera features such as digital zoom, megapixel resolution, and video analytics are not available for analog models.
Expensive Cabling – Analog cameras aren’t recommended for some large-scale surveillance applications because of the complicated and expensive cabling required.
Pros of IP Surveillance
Utilizes existing network – An IP camera acts just like any other network device. This allows for flexible, cost-effective installation anywhere along the existing network.
Easy remote access – Each IP camera features its own built-in web sever so you can access footage and control camera functions remotely from almost anywhere.
Megapixel Resolution – Some IP cameras offer very high resolution which can actually reduce the overall number of cameras needed..
Cons of IP Surveillance
Price – Since IP cameras feature more built-in technology, the initial cost tends to be higher than with analog cameras.
Bandwidth requirements – Calculating network bandwidth requirements is an important factor when configuring an IP surveillance solution.
